KASEN KABBIT - Product and Electrical Parameters; Dimensions and Features

t
Tianjin APT Science and Technology Co., Ltd.
1001, Building 5 HuaDing, No.1 HuaKe 3 Road, 2 TEL: 86 22 2634 5859
Binhai hi-tech Industrial Development Zone, Tianjin, China FAX: 86 22 8371 9955
Email: apt@ap develop.com
1． Product Name
TFT LCD display
Model : KASEN TFT 500C
3． Electrical Parameters
2.2inch IPS screen
24V/36V/48V battery supply
Rated operating current : 40mA
Off leakage current < 1uA
Max output current to controller : 100mA
Operating temperature : -20～70℃, Storage temperature : -30～80℃
4． Dimensions & Material
Product shell is ABS, transparent window is made with high strength Acrylic.
Dimensions : host/L79mm*W40mm*H18mm
5． Features
Suitable for low temperature，Max -20℃.
High-contrast 2.2inch IPS colorful matrix screen.
Ergonomic external button design, easy to operate.
