Tire Changer KT-830 User’s Manual
15
3.3 Main installation procedure
3.3.1 Standard configuration installation
◆ The first step: unscrew wooden pallet fixing screws, tire changer placed at the
installation site. (installation site must conform to the requirements.
◆ The second step: unscrewing the bolts from the box, the column is installed in the
machine box on the specified position, tighten the bolts.
◆ The third step: Fix the inflation box on the left side of tower with box.
◆ The forth step: Fix the turbo blast at back of machine box.
