KaZAM WeeRide - Support Bar Parts List

5
Hex Head Bolt
Washer
Nut
Allen Head Bolt
Washer
Allen Head Bolt
Extension Arm Left
Rear Support Bar
Hex Head Bolt
Hex Head Bolt
Hex Head Bolt
Washer
Bracket (FRONT)
Bracket Insert (FRONT)
Resin Bumper
Nut
Front Support Bar
Bar Support
Allen Head Bolt
Washer
Extension Arm Right
Washer Nut
Bracket (REAR)
Washer
Washer
Bracket
Bracket Insert
SUPPORT BAR PARTS LIST
FIG. 1
ENGLISH
manual WeeRide.indd 5 11/01/11 03:14
Thumb Knob
Washer
