Wireless Ethernet PtP & MP System Operations Manual
WES CONFIGURATION TABLE
KBC recommends that a spreadsheet of the wireless system be kept on hand for
reference. A worksheet providing all of the default settings is included in the shipment.
These settings along with any changes should be kept and tracked in a format similar to
the example provided below:
S/N
Device
Name
Type
IP
Channel &
Frequency
GUI
Password
08516
Head End 1
SP Host
192.168.1.200
0; 5745
abcsecurity
08517
PTZ Cam
Client
192.168.1.201
0; 5745
abcsecurity
08518
Head End 2
MP Host
192.168.1.202
7; 5825
abcsecurity
08519
Plate
Camera
Client
Patch
192.168.1.203
7; 5825
abcsecurity
08520
Front Gate
Client
192.168.1.205
7; 5825
abcsecurity
Configurations shown above are not default settings. Information shown only to
indicate what should be recorded when changes are made to the default settings.
20
Wireless Ethernet PtP & MP System Operations Manual
WES SPECIFICATIONS
For product improvement, design and specifications are subject to change without notice.
RF MODULES
Power Output 50 W EIRP @ 5.8 GHz (maximum)
Transmitting Frequency 5725 – 5825 MHz (U-NII-3 ISM)
Channel Capacity 5 non-overlapping channels
5745, 5765,5785, 5805, 5825 MHz
Modulation OFDM
Latency <10 milliseconds
Sensitivity -82 dBm fir maximum data rate
Polarization Linear, vertical only
Antenna Type & Gain Omni (WAPOM, WSUOM): 2.5 dBi @ 5.8 GHz
Small patch (WES-2500; WAP, WSU): 7.8 dBi @ 5.8 GHz
Large patch (WES-2-4; WSUP): 16.7 dBi @ 5.8 GHz
Small patch in 18 inch parabolic dish: 24 dBi @ 5.8 GHz
Beam Width Omni: 360⁰; Small Patch: 90⁰; Large Patch: 24⁰; Dish: 8⁰
Data Throughput Rate Up to 20 Mbps, Standard Mode; Up to 50+ Mbps, Super
Mode
FCC ID JRRWES
IC 4887A-WES
MANAGEMENT
Interface 10/100 Base T, half/full duplex, rate auto-negotiated (802.3
compliant)
Frequency Selection Physical: 8-position rotary switch; Software: pull down and
select manual switch override capability (see pages 14-15)
Web browser GUI Password protected internal web browser interface
configuration pages. Compatible with Internet Explorer and
Mozilla Firefox.
Access Method Time division duplexing/Time division multiple access
(TDD/TDMA)
Protocols Used IPV4, UDP, TCP, ICMP, Telnet. HTTP. FTP, SNMP. Network
management: http
MECHANICAL
Physical Environmentally protected, billet aluminum, powder coated
housing with UV stabilized PVC radome
Dimensions (WES-2500 individual modules; WAP, WSU): 92.68 mm x
44.55 mm x 91.69 mm; (WES-2-4 individual modules,
WSUP): 170.48 mm x 54.55 mm x 170.48 mm; (WAPOM,
WSUOM): 91.61 mm x 91.68 x 50.26 mm
Weight (WES-2500 individual modules, WAP, WSU): 0.4 Kg; (WES-
2-4 individual modules, WSUP): 0.7 Kg; (WAPOM, WSUOM):
0.4 Kg
POWER
Power Requirements 12-20 VDC @ 3 W (Reverse voltage protected
Power Method Power over Ethernet, mid-span compliant via power injection
module (PIM)
Connector RJ-45, in & out of PIM as well as into LAN port of WEM
Cable Specifications 100 meters max, 24 AWG Cat5e recommended
