KDK 20AUH - Page 13

4. Parts List
12
30AUH
No. Part No. Part Name Q'ty Remark
1 FFV5510008H Shutter 3
2 FFV5520010H Shutter Set Plate 2
3 FFV7010013S Washer 1
4 FFV5560016S Shutter Spring 1
5 FFV0710008H Coupling Rod 1
6 FFV4600001H Plastic Rivet 4
7 FFV7000080S Plus Truss Screw 6 For Fixing Shutter Set Plate
8 FFV1600076S Frame Assy. 1
9 FFV7000005S Set Screw 4 For Fixing Motor Assy.
10 FFV7010002S Plain Washer 1 For Fixing Earth Lead
11 FFV7010028S Spring Washer 1 For Fixing Earth Lead
12 FFV7000006S Bind Screw 1 For Fixing Earth Lead
13 FFV4300118S Orifice Assy. 1
14 FFV0400020H Blade 1 Gray
15 FFV5500017S Spinner 1
16 FFV0760026S Condenser Box 1
17 FFV0740009S Cord Clip 2 For Fixing Power Cord & Motor Lead
18 FFV7000073S Truss Screw 6 For Fixing Cord Clip & Condenser Cover
19 FFV0970006S Condenser Cover 1
No. Part No. Part Name Q'ty Remark
20 FFV3700262S Motor Assy. 1 For 220-240V,50Hz
(20) FFV3700272S Motor Assy. 1 For 110-127V,60Hz
21 FFV0750152S Condenser 1 440V,0.9uF,For 220-240V,50Hz
(21) FFV0750160S Condenser 1 250V,2.6uF,For 110-127V,60Hz
22 FFV0900024S Connector 2
23 FFV3470001S Butt Connector 1
24 FFV4620024S Power Cord 1
No. Part No. Part Name Q'ty Remark
25 FFV4020164S Name Plate 1 Sticked on Frame Assy.,For Style A
(25) FFV4020165S Name Plate 1 Sticked on Frame Assy.,For Style B
(25) FFV4020166S Name Plate 1 Sticked on Frame Assy.,For Style C
26 FFV4710173S Pad A 4
27 FFV4650013S Poly Cover 1 For Main Body Packing
28 FFV4710130S Paper Pad 1
29 FFV9000442S Packing Case Assy. 1 For Style A
(29) FFV9000443S Packing Case Assy. 1 For Style B
(29) FFV9000444S Packing Case Assy. 1 For Style C
30 FFV0010148S Accessory Set 1
Mechanical & Metal Section
Electrical Section
Packing & Accessories & Label Section
!
!
!
!
!
!
!
!
