4. Parts List
13
20ALH
No. Part No. Part Name Q'ty Remark
1 FFV5510016H Shutter (Small) 2
2 FFV5510017H Shutter (Big) 1
3 FFV5520008H Shutter Set Plate 2
4 FFV7010013S Washer 1
5 FFV5560014S Shutter Spring 1
6 FFV0710013H Coupling Rod 1
7 FFV4600001H Plastic Rivet 4
8 FFV7000005S Set Screw 8
For Fixing Shutter Set Plate & Motor Assy.
9 FFV1600075S Frame Assy. 1
10 FFV7010002S Plain Washer 1 For Fixing Earth Lead
11 FFV7010028S Spring Washer 1 For Fixing Earth Lead
12 FFV7000006S Bind Screw 1 For Fixing Earth Lead
13 FFV4300107S Orifice 1
14 FFV0400084S Blade 1 Gray
15 FFV5500017S Spinner 1
16 FFV3400101S Louver Assy. 1
17 FFV0760026S Condenser Box 1
18 FFV0740009S Cord Clip 2 For Fixing Power Cord & Motor Lead
19 FFV7000073S Truss Screw 6 For Fixing Cord Clip & Condenser Cover
20 FFV0970006S Condenser Cover 1
No. Part No. Part Name Q'ty Remark
21 FFV3700260S Motor Assy. 1 For 220-240V,50Hz
(21) FFV3700269S Motor Assy. 1 For 110-127V,60Hz
22 FFV0750150S Condenser 1 250V,2.7uF,For 220-240V,50Hz
(22) FFV0750159S Condenser 1 250V,2.0uF,For 110-127V,60Hz
23 FFV0900024S Connector 2
24 FFV3470001S Butt Connector 1
25 FFV4620024S Power Cord 1
No. Part No. Part Name Q'ty Remark
26 FFV4020167S Name Plate 1 Sticked on Frame Assy.,For Style A
(26) FFV4020168S Name Plate 1 Sticked on Frame Assy.,For Style B
(26) FFV4020169S Name Plate 1 Sticked on Frame Assy.,For Style C
27 FFV4710174S Pad A 2 Mark With"20AL94002"
28 FFV4710175S Pad B 2 Mark With"20AL94003"
29 FFV4650010S Poly Cover 1 For Main Body Packing
30 FFV4710128S Paper Pad 1
31 FFV9000445S Packing Case Assy. 1 For Style A
(31) FFV9000446S Packing Case Assy. 1 For Style B
(31) FFV9000447S Packing Case Assy. 1 For Style C
32 FFV0010148S Accessory Set 1
Mechanical & Metal Section
Electrical Section
Packing & Accessories & Label Section
!
!
!
!
!
!
!
!
