4. Parts List
14
25ALH
No. Part No. Part Name Q'ty Remark
1 FFV5510018H Shutter 3
2 FFV5520009H Shutter Set Plate 2
3 FFV7010013S Washer 1
4 FFV5560015S Shutter Spring 1
5 FFV0710007H Coupling Rod 1
6 FFV4600001H Plastic Rivet 4
7 FFV7000080S Plus Truss Screw 6 For Fixing Shutter Set Plate
8 FFV1600079S Frame Assy. 1
9 FFV7000005S Set Screw 4 For Fixing Motor Assy.
10 FFV7010002S Plain Washer 1 For Fixing Earth Lead
11 FFV7010028S Spring Washer 1 For Fixing Earth Lead
12 FFV7000006S Bind Screw 1 For Fixing Earth Lead
13 FFV4300108S Orifice 1
14 FFV0400085S Blade 1 Gray
15 FFV5500017S Spinner 1
16 FFV3400102S Louver Assy. 1
17 FFV0760026S Condenser Box 1
18 FFV0740009S Cord Clip 2 For Fixing Power Cord & Motor Lead
19 FFV7000073S Truss Screw 6 For Fixing Cord Clip & Condenser Cover
20 FFV0970006S Condenser Cover 1
No. Part No. Part Name Q'ty Remark
21 FFV3700261S Motor Assy. 1 For 220-240V,50Hz
(21) FFV3700276S Motor Assy. 1 For 110-127V,60Hz
22 FFV0750151S Condenser 1 440V,0.8uF,For 220-240V,50Hz
(22) FFV0750159S Condenser 1 250V,2.0uF,For 110-127V,60Hz
23 FFV0900024S Connector 2
24 FFV3470001S Butt Connector 1
25 FFV4620024S Power Cord 1
No. Part No. Part Name Q'ty Remark
26 FFV4020170S Name Plate 1 Sticked on Frame Assy.,For Style A
(26) FFV4020171S Name Plate 1 Sticked on Frame Assy.,For Style B
(26) FFV4020172S Name Plate 1 Sticked on Frame Assy.,For Style C
27 FFV4710176S Pad A 2 Mark With"30AL74002"
28 FFV4710177S Pad B 2 Mark With"30AL74003"
29 FFV4650010S Poly Cover 1 For Main Body Packing
30 FFV4710017S Paper Pad 1
31 FFV9000448S Packing Case Assy. 1 For Style A
(31) FFV9000449S Packing Case Assy. 1 For Style B
(31) FFV9000450S Packing Case Assy. 1 For Style C
32 FFV0010148S Accessory Set 1
Mechanical & Metal Section
Electrical Section
Packing & Accessories & Label Section
!
!
!
!
!
!
!
!
