Humidity sensor detectible condition. (24CHRVB only)
1 Humidity setting selector is stepless change between 45 %RH ~ 95 %RH.
2 The humidity detected by sensor may differ from the value on your hygrometer.
3 The product may turn on and off cause by the unstable environment humidity, you can improve it
by adjusting the humidity setting selector.
湿度传感器感应条件。(仅对于24CHRVB)
1 湿度传感器的设定范围为45%～95%。
2 湿度传感器感应湿度可能会和湿度计有出入。
3 根据环境的湿度变化，用户可以选择更换湿度传感器感应范围。
Motion sensor detectible condition. delay time is
15 minutes.
The following case may reduce sensitivity of the
motion sensor.
- Little movement by occupants.
- A room temperature is close to body temperature.
动作传感器感应条件。延时设定为15分钟。
以下情况可能会导致动作传感器感应不良。
用户非常轻微的活动。
室内温度非常接近人体温度。
OPERATION
运转
Fig.20 / 图20
Fig.21 / 图21
Humidity selector range from around 45% to 95%.
Factory setting is around 85%. (Fig.20)
Humidity timer selector range of positions from 0 to 6h.
Factory setting is 1 hour. (Fig.20)
Humidity timer selector position OFF. (Fig.21)
Humidity sensor OFF follows motion sensor operation.
SELECTOR INDICATION
(24CHRVB only)
调节器指示
湿度传感器湿度感应范围为45%～95%。出厂预设为85%。(图20)
湿度传感器延时设定范围为0～6h，出厂预设为1h。
(图20)
湿度传感器延时设定为OFF。(图21)
当延时设定为OFF时，换气扇只有在动作传感器感应到用户运动时进行
运转。
OUTSIDE
Human
activity
INSIDE
Fan
activity
Stop
When motion
is detected,
fan runs
Remains running
until 15 minntes
has passed.
The distance that motion can
be detected is limited to 3 m.
The field of view of the sensor
is 90°.
(Room temperature is 25°.)
Sensor
3 m
The above specification may be changed without further notice.
