KDK M56RG - Page 5

5
(
i)
(ii)
Do not screw Lower and
Upper Canopy Screws
Pipe
Upper Canopy
(with logo brand)
Pipe
Power Cord (from power supply)
Ceiling
Upper Canopy
Lower Canopy
Lower Canopy
Check Point After Installation
1. Insert the Lower and Upper Canopy to Pipe and the screw is not tightened.
2. Upper Canopy (with logo brand) is on top of Lower Canopy (no logo brand).
Check
B)
Assemble Pipe To Motor Assembly
1
1
Pull the power cord (from power supply) and insert into the Pipe hole as shown.
2
2
Insert Lower Canopy to the Pipe. Then insert Upper Canopy (with logo brand) to the Pipe.
