• Remove the screws together with the clamping brackets.
Figure 3: Removing screws and clamping brackets
• Place shield clamp on top.
Figure 4: Placing shield clamp on top
• Reattach the screws and clamping brackets using the screwdriver.
Figure 5: Reattaching the screws and clamping brackets
