3 Description of the device
3.1 Front view
Fig.3-1: Front view
1 ... Display 2 ... Operating button
3 ... Cover of USB or charging socket 4 ... Output for laser radiation (mirror)
3.2 Rear view
Fig.3-2: Rear view
1 ... Type plate 2 ... Magnets
3 ... Recesses for measuring aid
