A2xxOperation and handling
Operating instructions V1.01
34
© KEBA
ss Second (2-digit)
Personalization
KeMes A2xx can be personalized. This personalization is shown when
switching on the device.
In order to personalize KeMes A2xx, a connection to the internal memory of
the device must be established. The KEMES.INI file can then be edited using
a text editor, such as Microsoft
®
Editor.
When first opening the file, the following content can be seen:
[USER]
;user name line 0 (max. 16 char.)
NAME0=
;user name line 1(max. 16 char.)
NAME1=
Max. 16 characters can be entered per line in fields NAME0 and NAME1. Um-
lauts cannot be displayed.
Example:
[USER]
;user name line 0 (max. 16 char.)
NAME0=Company
;user name line 1(max. 16 char.)
NAME1=Operator
After editing, the file must be saved and the connection to KeMes A2xx must
be disconnected. The next time KeMes A2xx is switched on, the entered text
appears on the display.
Connecting the device and PC
The internal memory of the device can be accessed over the USB interface
in order to transmit the recorded measurement data to a PC and personalize
the device.
In order to establish a connection, the device must be switched on. Proceed
as follows to establish the connection:
1) Connect the USB cable to the device and PC. The message --DISC--
Connect? appears on the display.
2) Briefly press the operating button once to establish the connection. The
message --DISC-- Disconnect? is shown on the display.
The device is integrated onto the PC as a USB removable storage device
and is now connected. Using a file explorer, the data in the internal memory
of the device can be accessed.
In order to disconnect the device from the PC, proceed as follows:
1) Briefly press the operating button on the device once. The message --
DISC-- Connect? appears on the display.
2) Unplug the USB cable from the device and PC.
