1. On off push button
To turn the intelliPuff on, push the on off button –
a green LED will indicate the unit is on.
To turn off the intelliPuff, push the on off button –
the green LED will go out.
2. Test eye
This is useful for user training; it will not return an IOP measurement.
3. Printer active LED
When lit, this indicates the printer is activated; replacing the
handset in the cradle will force a print. Alternatively a print can
be forced at any time using the print button on the handset.
4. Printer cover
Access to the printer paper is via this cover, use your finger in
the lip on the top of the cover and gently pull towards you to
open the printer cover.
5. Serial port
The serial port is used for calibration, systems checking and
data output (located on rear of instrument).
6. Power input
Insert the low voltage power lead (located on rear of instrument)
use only Keeler power supplies.
7. Forehead rest
Push to release, or push to return the
forehead stabiliser to its discrete position.
8. Right (OD) / Left (OS) indicators
These will indicate the eye to be
measured; the OD/OS button will
toggle between these indicators.
9. Names of controls and components
82
1
3
4
5
6
