14
9. Names of controls and components
15. Puff tube and lens
The puff tube and puff lens is the part of the Pulsair intelliPuff
through which the Pulsair is aligned and a gentle puff of air is
emitted.
16. Alignment LEDs
The two green LED’s located on the front of the hand unit act
as a guide when you are lining up the patient’s eye to take a
reading.
16
15
