Outdoor Unit Sizes 9K-12K (208-230V) (continued)
Panel Plate
noitartsullIerudecorP
4) Remove the front panel screws (7)
and remove the front panel.
5) Remove the water collecting cover
screws (1) and remove the water
collecting cover.
Front Panel
Water Collecting Cover
