DIMENSIONS
Sizes 9K and 12K
Table 3 — Dimensions
Fig. 1 — Sizes 9K and 12K
System Size Height (H) in. (mm) Width (W) in. (mm) Depth (D) in. (mm) Weight-Net lbs. (kg)
9K (208/230V) 27.64 (702) 33.27 (845) 14.29 (363) 107.59 (48.8)
12K (208/230V) 27.64 (702) 33.27 (845) 14.29 (363) 108.47 (49.2)
13.78 (350)
B
1.42 (36) A3
7.83(199) A2
1.10(28)
D3
13.19(335) 14.45(367)
D2
3.62 (92)
2.40 (61)
H1
H2
35.98(914) W1
33.27(845) W
21.86(540) A
27.64(855) W3
27.64 (702)
H
0.51(13)
13.66(347) D
