KeepRite DLCPRA Series - Page 5

32808000903 Specifications subject to change without notice. 5
Sizes 18K and 24K
Fig. 2 — Sizes 18K and 24K
SYSTEM SIZE HEIGHT (H) IN. (MM) WIDTH (W) IN. (MM) DEPTH (D) IN. (MM) WEIGHT-NET LBS. (KG)
18K (208/230V) 31.89 (810) 37.24 (946) 16.14 (410) 135.4 (61.4)
24K (208/230V) 31.89 (810) 37.24 (946) 16.14 (410) 145.1 (65.8)
0.94 in(24 mm)
2.87 in (73 mm)
