KeepRite DLCPRA Series - Page 56

56 Specifications subject to change without notice. 32808000903
Outdoor Unit Sizes 18K-24K (208-230V) (continued)
Panel Plate
Procedure Illustration
6) Remove the water collecting cover
screws (2) and then remove the water
collecting cover.
7) Remove the rear screen screws (2).
Next, remove the rear net.
Water Collecting Cover
