GP Acoustics reserve the right, in line with continuous research and development, to amend or change specifications without prior notice. E. & O.E.
Design Two-way bass reflex Two-way bass reflex Three-way bass reflex
Drive units
130mm (5.25in.) Uni-Q 165mm (6.5in.) Uni-Q 2 x 130mm (5.25in.) LF
19mm (0.75in.) alu dome HF 19mm (0.75in.) alu dome HF 130mm (5.25in.) Uni-Q
19mm (0.75in.) alu dome HF
Frequency response 50Hz - 40kHz 45Hz - 40kHz 65Hz - 40kHz
Crossover frequency 2.5kHz 2.5kHz 280Hz - 2.8kHz
Amplifier requirements
10 - 100W 15 - 120W 15 - 150W
Sensitivity (2.83V/1m) 88dB 89dB 90dB
Maximum output 108dB 110dB 111dB
Nominal impedance 8Ω 8Ω 8Ω
Magnetic shielding Yes Yes Yes
Weight 4.5kg (9.9lbs) 6.45kg (14.2lbs) 8.8kg (19.4lbs)
Dimensions 301 x 175 x 261 mm 365 x 220 x 327 mm 165 x 512 x 255 mm
(H x W x D) 11.8 x 6.9 x 10.3 in. 14.4 x 8.7 x 12.9 in. 6.5 x 20.1 x 10 in.
Design Two and a half-way bass reflex Two and a half-way bass reflex Three-way bass reflex
Drive units
130mm (5.25in.) LF 165mm (6.5in.) LF 2 x 165mm (6.5in.) LF
130mm (5.25in.) Uni-Q 165mm (6.5in.) Uni-Q 165mm (6.5in.) Uni-Q
19mm (0.75in.) alu dome HF 19mm (0.75in.) alu dome HF 19mm (0.75in.) alu dome HF
Frequency response 40Hz - 40kHz 36Hz - 40kHz 33Hz - 40kHz
Crossover frequency 2.5kHz 2.5kHz 180Hz - 2.5kHz
Amplifier requirements
15 - 130W 15 - 150W 15 - 200W
Sensitivity (2.83V/1m) 88dB 90dB 91dB
Maximum output 109dB 111dB 113dB
Nominal impedance 8Ω 8Ω 8Ω
Magnetic shielding Yes Yes Yes
Weight 10.2kg (22.5lbs) 14.0kg (30.9lbs) 16.3kg (35.9lbs)
Dimensions 815 x 175 x 261 mm 865 x 220 x 327 mm 942 x 220 x 327 mm
(H x W x D) 32 x 6.9 x 10.3 in. 34 x 8.7 x 12.9 in. 37 x 8.7 x 12.9 in.
Plinth Dimensions 28 x 250 x 295 mm 28 x 288 x 348 mm 28 x 288 x 348 mm
(H x W x D) 1.1 x 9.8 x 11.6 in. 1.1 x 11.3 x 13.7 in. 1.1 x 11.3 x 13.7 in.
centrebookshelfbookshelf
floorstanderfloorstanderfloorstander
Walnut veneerAmerican Walnut Light Oak veneerDark AppleBlack Ash
specifications
iQ90 floorstander iQ70 floorstander
finishes
As front speakers for high-end home theatre or as a
stereo pair, the new iQ90 features the new full size
165mm (6.5in.) Uni-Q® and two new low distortion
dual composite cone bass drivers of the same size.
The iQ90 achieves gratifyingly precise 3D imaging,
breathtaking dynamics and real depth to the
performance while maintaining lavishly tight and
controlled bass thanks to the new internal ‘labyrinth’
system. Meticulously engineered, right down to the
discreet plinths provided for greater stability.
The iQ90 represents outstanding quality normally
associated with more expensive speakers.
The new iQ70 is an assertive full bandwidth bass reflex
floorstander that reproduces music and movie soundtracks
with equal clarity and flair. The combination of the new
165mm (6.5in.) Uni-Q, ‘tangerine’ waveguide and high
performance dual composite bass driver of the same size
radiates a faultlessly detailed 3D image evenly throughout
the room. Bass is kept tight and controlled thanks to the
ingenious new internal ‘labyrinth’ system. With discreet
plinths for added stability, the iQ70 has the looks,
engineering integrity and acoustic performance to deliver
uncompromised listening pleasure with whatever media
you choose.
iQ50 floorstander iQ30 bookshelf
The new iQ50 builds on the award-winning formula of
its predecessors. With the stunning new 130mm
(5.25in.) Uni-Q and ‘tangerine’ waveguide coupled
with a new lightweight dual composite long-throw
bass driver of the same size. The iQ50 is an
accomplished performer as satellites in a 5.1 package
or as a dedicated two-channel system. Attention to
detail is evident throughout, right down to the
discreet plinths provided for greater stability. The
inherent sweetness and combined assertiveness of the
iQ50 represents outstanding value for those who take
sound seriously.
The new iQ30 is an incredibly versatile music or home
entertainment speaker with a seductive lightness of
touch. With the sensational new 165mm (6.5in.) Uni-Q
it has a lyricism and depth not normally associated with
bookshelf speakers. Delivering an excellent dynamic
expression with a bass response that is deep and
expansive, the characteristically wide dispersion makes
the iQ30 as easy to position as they are to drive.
Whether stand-mounted or on a shelf, listening to the
iQ30 is like re-experiencing your favourite tracks or
movies for the very first time.
iQ10 bookshelf iQ60c centre
Where space is at a premium, the new iQ10 proves
that size isn’t everything. With the sensational new
130mm (5.25in.) Uni-Q driver array in a reflex-ported
cabinet, the calibre of its acoustic performance is out
of all proportion to its modest dimensions. As satellite
speakers in a 5.1 system, their realism delivers an
engrossingly intricate 3D soundscape that adds real
depth to the viewing experience. Musical, efficient and
transparent, iQ10 is a minor miracle of audio
engineering that gives you the listening pleasures of
KEF’s latest technology at a gratifyingly modest price.
The centre channel is critical to the success of any 5.1
home cinema system, so the new iQ60c features the
same critical elements as the rest of the range to bring
any movie to life. The new 130mm (5.25in.) Uni-Q
flanked by two new dual composite, low distortion
bass drivers of the same size, ensure vocals are
uncannily clear and precisely located - whatever the
volume. Lower frequency effects are equally involving
and delivered with real clout, immersing the listener in
a 3D soundscape. The iQ60c is a valuable addition to
any home cinema system.
Not all models/finishes are available in all markets. Contact your local dealer for specialist range details.
