Keiser 3103XX User Manual

HALF RACK, HALF RACK LONG BASE
ASSEMBLY INSTRUCTIONS
07
PARTS LIST
Description Description
Qty Qty
F
Bar Catch Set
1
C
Posts*
2
E
Weight Stacks
2
I
J
K
L
M
Power Displays
eChip Set
Extension Strap Set
Barbell Attachment Set
Weight Stack Decals Set
2
1
1
1
1
D
Cantilever Spotting Bars
2
B
Bottom Frames*
2
A
Power Modules
2
G
H
Bench Positioner Bar with Cable Tray
Cross Brace
1
1
NOTE: Optional Olympic Lifting Insert and Insert Platforms (including optional accessories) not shown. Check for any damage or missing
parts. If parts are damaged or missing, contact your local dealer, distributor, or Keiser Customer Support by telephone at 1 559 256 8000.
All hardware required for assembly included and fastened on parts (anchor fasteners not included).
A
B
C
D
E H
I
J
K L
M
G
F
IMPORTANT:
Power Modules and
Bottom Frames
are connected by
Cables and Wires.
Keep Connected.
Items not to scale
Figure 4. Half Rack Parts List
* Model 3106XX 9' Half Rack Long Base shown. Bottom Frames and Posts for models 3103XX, 3104XX, and 3105XX have similar appearance.
