Series 2260B
Programmable Power Supplies Verification and Adjustment Manual Section 5:
Verification test record forms
077104802 / November 2016 5-9
Constant current tests:
Current programming
and measurement
Model Minimum
specifications
Results Maximum specifications
Minimum current out 800-1 -2 mA +2 mA
800-2 -4 mA +4 mA
800-4 -6 mA +6 mA
Measurement accuracy 800-1 -2 mA +2 mA
800-2 -4 mA +4 mA
800-4 -6 mA +6 mA
Rated current out 800-1 0.997 A 1.003 A
800-2 1.994 A 2.006 A
800-4 3.936 A 4.064 A
Measurement accuracy 800-1 0.997 A 1.003 A
800-2 1.994 A 2.006 A
800-4 3.936 A 4.064 A
CC load regulation Model Minimum
specifications
Results Maximum specifications
800-1
-6.00 mA
+6.00 mA
800-2
-7.00 mA
+7.00 mA
800-4
-9.00 mA
+9.00 mA
CC line regulation Model Minimum
specifications
Results Maximum specifications
800-1
-6.00 mA
+6.00 mA
800-2
-7.00 mA
+7.00 mA
800-4
-9.00 mA
+9.00 mA
