Keithley 2302 Quick Results Guide

Front panel operation 21
Programming examples: long integration measurements
The following command sequence will trigger and return one long integration measurement:
Battery channel (#1)
Charger channel (#2)
Command Description
SENS:RANG 5 ‘ Select 5A range.
VOLT 15 ‘ Set output voltage to 15V.
CURR 0.75 ‘ Set current limit to 750mA.
OUTP ON ‘ Turn output on.
SENS:LINT:TLEV:RANG 0.5 ‘ Select 1A trigger level range.
SENS:LINT:TEDG RISING ‘ Select rising trigger edge to initiate measurement.
SENS:LINT:TLEV:ONE 0.1 ‘ Set trigger level to 100mA for 1A trigger level range.
SENS:LINT:TIME:AUTO ‘ Set integration time automatically for single pulse.
SENS:FUNC “LINT” ‘ Select long integration function.
READ? ‘ Trigger and return one reading and reading shown on
display.
Command Description
SENS2:RANG 5 ‘ Select 5A range.
SOUR2:VOLT 15 ‘ Set output voltage to 15V.
SOUR2:CURR 0.75 ‘ Set current limit to 750mA.
OUTP2 ON ‘ Turn output on.
SENS2:LINT:TEDG RISING ‘ Select rising trigger edge to initiate measurement.
SENS2:LINT:TLEV 0.1 ‘ Set trigger level to 100mA.
SENS2:LINT:TIME:AUTO ‘ Set integration time automatically for single pulse.
SENS2:FUNC “LINT” ‘ Select long integration function.
READ2? ‘ Trigger and return one reading and reading shown on
display.
