4-14 Long Integration Measurements
:SENSe[1]
:LINTegration
:TLEVel <NRf>
:RANGe <NRf>
:MILLiamp <NRf> Model 2306-PJ when on 500mA current range. Set
trigger le
vel range (10mA, 100mA, or
500mA). The parameter <NRf> sent with this
command causes the trigger to be set with the
trigger level setting of HALFamp, HUNDred,
or TEN. Queries receive responses of 0.5, 0.1,
or 0.01 accordingly. For example, if a value of
75mA is sent with the command, a value of
0.1A will be returned as a response to a query.
:TEDGe <name> Select trigger edge to initiate the measurement:
RISING, FALLING, or NEITHER.
RISING
:TimeOUT <NRf> Specify length of timeout: 1–63 (sec). 16
:SEARch <b> Enable or disable pulse search. ON
:FAST <b> Enable or disable long integrations fast
readings.
OFF
:DETect <b> Enable or disable pulse
detection mode. OFF
:SENSe2 SENSe subystem for channel #2
(charger channel):
:FUNCtion “LINTegration” Select long integration measurement function. VOLT
:LINTegration Long integration conf
iguration:
:TIME <NRf> Set integration time (in sec): X to 60 (where X
is 0.850 for 60Hz, or 0.840 for 50Hz).
1
:AUTO Integration time set automatically.
:TLEVel <NRf> Set trigger level in amps: 0–5 (5mA resolution). 0.0
:TEDGe <name> Select trigger edge to initiate the measurement:
RISING, FALLING, or NEITHER.
RISING
:TimeOUT <NRf> Specify length of timeout: 1–63 (sec). 16
:SEARch <b> Enable or disable pulse search. ON
:FAST <b> Enable or disable long integrations fast
readings.
OFF
:DETect <b> Enable or disable pulse
detection mode. OFF
READ[1]? Trigger and return one reading for battery channel (#1).
READ2? Trigger and return one reading fo
r charger channel (#2).
Table 4-2
SCPI commands — long integration measurements (cont.)
Command Description Default
