Table 12-3
OUTPut command summary (refer to Tables 2-3 and 5-2)
Command Description
Default
pa
rameter
SCPI
:OUTPut[1] OUTPut subsystem for channel #1 (battery channel) ✓
[:STATe] <b> Turn output ON or OFF. OFF ✓
[:STATe]? Query state of output. ✓
:BANDwidth Specifies HIGH or LOW bandwidth when the output state is ON
an
d current range is set to 5A. When output is OFF, the band-
width is LOW. When current range is 5mA, bandwidth is
LO
W.
LOW
1
:BANDwidth? Query bandwidth setting for when output is ON and not on
5mA range.
:IMPedance <NRf> Specifies the output impedance to apply 0 (OFF) to 1Ω (max) in
10mΩ steps
.
0
:IMPedance? Query impedance setting.
:RELay1 <name> Close (ONE) or open (ZERO) relay control circuit for relay 1.
2
ZERO
:RELay1? Query the value at relay 1 port pin digital I/O.
2
:RELay2 <name> Close (ONE) or open (ZERO) relay control circuit for relay 2.
2
ZERO
:RELay2? Query the value at relay 2 port pin digital I/O.
2
:RELay3 <name> Close (ONE) or open (ZERO) relay control circuit for relay 3.
2
ZERO
:RELay3? Query the value at relay 3 port pin digital I/O.
2
:RELay4 <name> Close (ONE) or open (ZERO) control circuit for relay 4.
2
ZERO
:RELay4? Query the value at relay 4 port pin digital I/O.
2
:OUTPut2 OUTPut subsystem for channel #2 (charger channel) ✓
[:STATe] <b> Turn output ON or OFF. OFF ✓
[:STATe]? Query state of output. ✓
:BANDwidth Specifies HIGH or LOW bandwidth when the output state is ON
an
d current range is set to 5A. When output is OFF, the band-
width is LOW. When current range is 5mA, bandwidth is LOW.
HIGH
:BANDwidth? Query bandwidth setting for when output is ON and not on
5mA range.
:BOTHOUTON
:BOTHOUTOFF
Turns both power supply channels ON.
3
Turns both power supply channels OFF.
3
1
Default is HIGH for firmware version B02 and lower (does not apply to Model 2306-PJ).
2
Model 2306-VS does not support relay control.
3
No query or short form exists.
SCPI Tables 12-5
