SECTION3
IEEE-488
Reference
+
3.6.3
C -
Calibration
Purpose
Format
Parameters
3-22
To calibrate
the
Model236/237
/238
instrument.
C
step
{,value)
X
Where:
step
=
command
option
number
value =
measured
or
sourced calibration value
cox
C1X
C2X
C3,VmsrX
C4X
CS,VmsrX
C6X
C7,VmsrX
C8X
C9,VmsrX
C10X
C11,VmsrX
C12X
C13,VmsrX
C14X
C15,VmsrX
C16X
C17,VmsrX
C18X
C19,VmsrX
C20X
C21,VmsrX
C22X
C23,VmsrX
C24X
C25,VmsrX
C26X
C27,msrX
C28X
C29,msrX
Enter calibration procedure
Common
mode
adjustment
Set
up
+
1.1
V
source
and
measure offset calibration
Vmsr
=Measured
voltage
Set
up
+
1.1
V
source
and
measure gain calibration
Vmsr
=Measured
voltage
Set
up
-1.1
V
source
and
measure
offset calibration
Vmsr
=Measured
voltage
Set
up
-1.1
V
source
and
measure gain calibration
Vmsr
=Measured
voltage
Set
up
+
11
V
source
and
measure offset calibration
Vmsr
=Measured
voltage
Set
up
+
11
V
source
and
measure
gain
calibration
Vmsr
=Measured
voltage
Set
up
-11
V
source
and
measure offset calibration
Vmsr
=Measured
voltage
Set
up
-11
V
source
and
measure gain calibration
Vmsr
=Measured
voltage
Set
up
+
110V source
and
measure offset calibration
Vmsr
=Measured
voltage
Set
up
+
110V source
and
measure
gain calibration
Vmsr
=Measured
voltage
Set
up
-110V
source
and
measure offset calibration
Vmsr
=Measured
voltage
Set
up
-110V
source
and
measure
gain calibration
Vmsr
=Measured
voltage
237/238 only
Set
up+
1.1kV (237)
or+
1A (238) source
and
measure offset
calibra-
tion
msr
= Measured voltage (237)
or
current (238)
Set
up
+ 1.1kV (237)
or
+ 1A (238) source
and
measure
gain
calibra-
tion
msr
= Measured voltage (237)
or
current (238)
+
