Keithley 2635A Quick Start Guide

2600AS-903-01 Rev. A / September 2008 1
Series 2600A SourceMeter® Instruments Quick Start Guide
SMU Connectors
2601A/2611A/2602A/2612A (diagram shown for 2602A/2612A)
DUT Connections
Two-wire Connection
Model 2635A/2636A two-wire connections (local sensing, non-floating)
1 - CHANNEL A and CHANNEL B 1 - CHANNEL A and CHANNEL B Triax connectors
2 - DIGITAL I/O 2 - DIGITAL I/O
3 - IEEE-488 3 - IEEE-488
4 - Cooling exhaust vent 4 - Cooling exhaust vent
5 - Chassis ground 5 - Chassis ground
6 - Low noise chassis ground 6 - RS-232
7 - RS-232 7 - TSP-Link
8 - TSP-Link 8 - Power module
9 - Power module 9 - Triax connector
10 - LAN 10 - Phoenix connector on ground module
11 - LAN
Model 2635A/2636A
7
