Replaceable Parts
6-7
Table 3. Mass Terminated Connector Card for 7012-C, Parts List
Circuit Desig. Description Keithley Part No.
BRACKET
CONNECTOR SHIM
SHIELD
STANDOFF
7011-307
7011-309
7011-311
ST-203-1
C101 CAP,.1UF,20%,50V,CERAMIC C-365-.1
CR101-104 DIODE,SILICON,IN4148 (DO-35) RF-28
E101,102 BEAD, FERRITE CT-9
J1004 CONN, 96-PIN, 3 ROWS CS-514
K101-104 RELAY, ULTRA-SMALL POLARIZED TF2E-4.5V RL-162
P1002,1003 CONNECTOR, FEMALE CS-748-3
Q101 TRANS,NPN SILICON,BUK456-1000B TG-47
R101,102
R103
RES, 220,10%, 1/2W, COMPOSITION
RES,100K,5%,1/4W,COMPOSITION OR FILM
R-1-220
R-76-100K
