3.2.2 Seal Removal (If Necessary)
1. Turn the sealing disc over and remove the Spirolox® ring. Lift the end
of the ring with a screwdriver and uncoil the ring from the sealing disc
(Figure 3.14).
2. Remove the elastomeric seal carefully with a non-abrasive tool. Do
not damage the seal mating surface.
3.3 JS75L/LS, JS165L/LS, JS75XL/XLS, JS75LT/LTS, and
JS165LT/LTS Seal Disc Disassembly
1. Turn the sealing disc over and remove the seal retainer bolt. Thread locker is
used on the retainer bolt and may prove difficult to loosen. Use caution not to
damage sealing disc if using a vise or other means to hold seal disc while
loosening bolt.
2. Lift the retainer plate from the sealing disc.
3. Remove the elastomeric seal carefully with a non-abrasive tool (Figure 3.15).
Do not damage the seal mating surface.
