Kemlan CUBE - MINIMUM HEIGHT OF FLUE SYSTEM EXIT

INSTALLATION INSTRUCTIONS
MINIMUM HEIGHT OF FLUE SYSTEM EXIT
INSTALLATION TO COMPLY WITH AS/NZS 2918
Ver.20
3000
OR LESS
INCREASE FROM 1000 MIN
UNTIL CLEAR WITHIN 3000 OF
TOP OF FLUE
3000
ANY NEARBY
STRUCTURE
6000
MORE THAN 3000
600 MIN
3000
1000 MIN IF CLEAR WITHIN
3000 OF TOP OF FLUE
INCREASE AS NECESSARY UNTIL
NOTHING WITHIN 6000 OF THE FLUE
TOP
600 MIN
3000 OR LESS
MORE THAN 3000
DIMENSIONS IN MILLIMETRES
06/06/2023 13
