Kemlan CUBE - MINIMUM CLEARANCES; STEEL BENCH MEASUREMENTS

D
G
K
E
B
H
C
C
F
F
J
A B C D E F G H I J K
MEASUREMENT 120 300 125 338 654 540 1004 875 1114 570 300
I
MINIMUM CLEARANCES:
K
A
MINIMUM CLEARANCES FOR THE
KEMLAN CUBE
INSTALLED WITH DEFAULT FLUE KIT
Ver.20
1007
920
260
927
300
STEEL BENCH MEASUREMENTS:
FRONT VIEW
TOP VIEW
40
06/06/2023 3
