 Virtual Services may be created on either eth0 or eth1. Up to eth7 on Multi-Armed configurations

 Real Servers may exist on either the eth0 or up to the eth5 network. However, placing Real Server on

eth0 in a two-armed configuration is not recommended.

3. Direct Server Return – DSR example

1 – incoming request intercepted by LoadMaster

2 – routed to Test Server 1

3 – response from Test Server 1

4 – Response goes directly to Client without LoadMaster
