Kenmore 630.13952 - User Manual

Questions and Answers

W
wellstimothyJul 30, 2025
What to do if my Kenmore 630.13952 Dishwasher will not drain?
- A
  Alexandra BrownJul 30, 2025
  If your Kenmore Dishwasher isn't draining, start by checking for clogs in the drain. Ensure the drain operates freely after clearing any obstructions. Also, inspect the drain hose for kinks or blockages, and consider shortening or replacing it, adding a 20-inch high loop to prevent backflow. If you have a garbage disposal, make sure the plug has been removed. If the current measures approximately 0.68 A but the water still won't drain, the drain pump likely needs replacement. Check and reseat any loose connectors, replacing the wire harness if damaged. Finally, if the resistance falls between 23 - 28 ?, the control may need replacing; otherwise, replace the drain pump.
K
Kevin MorrisAug 4, 2025
Why is my Kenmore 630.13952 not filling with water properly?
- M
  Michelle SilvaAug 5, 2025
  If your Kenmore Dishwasher isn't filling with water, ensure the water supply is fully turned on and adjusted to the correct pressure. Clean out the water line and screen to remove any blockages. Check for leaks and drain any water from the base to disengage the float switch. If the voltage is not around 120V, check the connections. If the voltage is correct (about 120V), the water inlet valve might need replacement. Reseat any loose connectors, and if they are properly seated, consider replacing the flow meter or harness. If the resistance measures approximately 0 ?, the float switch is likely stuck closed and needs replacing. If the resistance is around 950 ?, the control may need to be replaced.
A
Andrea MillerAug 9, 2025
What to do if the Kenmore 630.13952 circulation pump is not running?
- J
  jbrownAug 9, 2025
  If your Kenmore Dishwasher's circulation pump isn't running or the dishes are still dirty after a cycle, and the dishwasher is not filling, refer to the 'Will Not Fill' troubleshooting section. Replace the heater assembly, which includes the water switch. If the current draw is approximately 11A, clear any obstructions from the filter and spray arms. If the pump doesn’t rotate freely, check for obstructions in the pump housing and remove them; if there are no obstructions, replace the pump. Ensure all connectors are properly seated, replacing the wire harness if damaged. If the resistance is approximately 0 ?, replace the circulation pump; otherwise, replace the door switch.
J
Jason BlevinsAug 14, 2025
How to fix a Kenmore 630.13952 dispenser that is not operating?
- T
  Thomas CobbAug 14, 2025
  If your Kenmore Dishwasher dispenser isn't working or rinse aid isn't being dispensed, try freeing a jammed cover by repeatedly opening and closing it, or replace the cover if it's damaged. Make sure connectors are properly seated; if they aren't, reseat them, and replace the wire harness if the connectors are damaged. If the actuator works but doesn't open the detergent dispenser cover or release rinse aid, replace the dispenser linkages. If the resistance is not between 2050 - 2250 ?, replace the dispenser actuator; otherwise, replace the control.
A
Angela AguirreAug 19, 2025
Why Kenmore 630.13952 Dishwasher has no heat, heating error or NTC error?
- P
  pamelawardAug 19, 2025
  If your Kenmore Dishwasher isn't heating, showing a heating error, or displaying an NTC error, first check if the spray arms are turning; if not, refer to the 'Circulation Pump Not Running' section. Check the NTC connections and replace the NTC if the connections are okay and the resistance isn't within these values: around 45840 ? at 77º F (25ºC), around 16542 ? at 22º F (50ºC), or around 11067 ? at 140º F (60ºC). If the thermostat is open, replace it. If the heating element is open, replace the heater. If neither is open, replace the pressure switch. If the pressure plate moves freely, replace the control; otherwise, replace the heater.
B
Barbara CruzAug 25, 2025
How to troubleshoot a Kenmore Dishwasher with no power?
- C
  Charlene LeonardAug 26, 2025
  To address a Kenmore Dishwasher with no power, first ensure the dishwasher's connections are correct; if they're improper, replace the cord/wiring with a minimum 14 AWG wire rated for 75°C. If the voltage isn't 120V, check for open circuit breakers or fuses. Reseat any connectors that aren't properly seated, and replace the wire harness if the connectors are damaged. If resistance is approximately 0 ?, replace the interference suppressor (RFI filter). If resistance isn't approximately 0 ?, replace the on/off switch. If resistance is approximately 0 ?, the control is shorted and should be replaced. If resistance isn't approximately 0 ?, replace the on/off switch. If resistance isn't approximately 0 ?, replace the interference suppressor.

Summary

SAFETY

General hazards

Warnings about tipping, hydrogen gas formation, and handling hot components.

Electrical shock; fire hazards

Precautions for electrical connections, grounding, and working with energized circuits.

Plumbing; scalding hazards

Safety measures for working with hot water supply lines and preventing scalding.

INSTALLATION

Pre-Install checklist

A list of checks before installation, including enclosure dimensions and water/power readiness.

Alignment

Instructions for positioning and leveling the dishwasher unit.

Electrical connection

Steps for safely connecting the dishwasher's electrical power supply.

Water connection

Guidance on connecting the hot water supply line to the inlet valve.

Drain and condensation hose connections

OPERATION

Control layout

COMPONENTS

Dishwasher components

Leveling feet (front and rear)

Drain pump

Specifications and troubleshooting for the drain pump.

Water inlet valve

Dispenser

Water circulation

REPAIR

Disassembly procedures

Steps to remove the outer door and toe kick for access to internal parts.

To flip dishwasher upside-down

Step-by-step guide to safely flip the dishwasher for maintenance.

To raise (block up) right side of tank

Water valves

Steps to access and remove the water valve, including connection hints.

Circulation pumps

Controls

Base mounted controls

Heaters

Procedures for accessing and removing the heater assembly.

Drain pumps

Steps to access and remove the drain pump.

Dispensers

FAULT DIAGNOSTICS

Customer service test program

Instructions for entering and using the customer service test program.

Error code displays

How to view error codes and a list of common error codes and priorities.

Dishwasher troubleshooting (No power, No heat, NTC errors)

Troubleshooting steps for issues like no power or heating errors.

Dishwasher troubleshooting (Dispenser, Drain, Circulation)

Troubleshooting for dispenser, drain, and circulation pump faults.

Dishwasher troubleshooting (Filling, Heater)

Troubleshooting steps for filling issues and heater diagnosing.

Water Leaking Past Doors

Customer self-help diagnosing

TECHNICAL SPECIFICATIONS

WIRING DIAGRAMS

Kenmore 630.13952 Specifications

General

Type	Built-In
Control Type	Electronic
Number of Wash Cycles	6
Place Settings	14
Color	Stainless Steel
Energy Star Certified	Yes
Heated Dry	Yes
Third Rack	No
Adjustable Upper Rack	Yes
Soil Sensor	Yes
Delay Start	Yes
Water Consumption	3.2 gallons per cycle
