- 3 -
7. OPERATION PRINCIPLE AND REPAIR METHOD OF ICEMAKER ..................................
7.1 Operation principle .........................................................................................................
7.2 Ice maker functions ........................................................................................................
8. CIRCUIT OF MICOM (DRAWER TYPE MODELS)..............................................................
8.1 Function .........................................................................................................................
8.2 PCB function ..................................................................................................................
8.3 Resistance specification of sensor .................................................................................
9. CIRCUIT OF MICOM (SWING TYPE MODELS)..................................................................
9.1 Function .........................................................................................................................
9.2 PCB function ..................................................................................................................
9.3 Resistance specification of sensor .................................................................................
10. EXPLODED VIEW AND REPLACEMENT PART LIST......................................................
35
36
38
39
39
43
47
48
48
52
56
57
SAFETY PRECAUTIONS
Please read the following instructions before
servicing your refrigerator.
1.Check the refrigerator for current leakage.
2.To prevent electric shock,unplug before
servicing.
3.Always check line voltage and amperage.
4.Use standard electrical components.
5.Don't touch metal products in the freezer
with wet hands.This may cause frost bite.
6.Prevent water from spiling on to electric
elements or the machine parts.
7.Before tilting the refrigerator, remove all
materials from on or in the refrigerator.
8.When servicing the evaporator, wear gloves
to prevent injuries from the sharp evaporator
fins.
9.Service on the refrigerator should be
performed by a qualified technician.Sealed
system repair must be performed by a CFC
certified technician.
