14
CAUTION
Be sure doors are set aside in a secure
position where they cannot fall and
cause personal injury, or damage to
the doors or handles.
Door Removal Instructions (Continued)
CAUTION
Drawer is heavy. Use caution when
lifting.
Once both doors are in place, ensure they
are aligned with each other and level (Please
see the “Installation” section for more details),
and replace the top hinge cover.
Removing Freezer Drawer
1 Remove 4 hex head drawer screws.
2 Lift up drawer to remove.
Remove
Hex Head
Drawer Screw
DO NOT
Remove
Other
Screws
DO NOT
Loosen
or
Remove
These 3
Hex
Screws
Replacing Freezer Drawer
1 Lower drawer back into place.
2 Replace 4 hex head drawer screws
and tighten.
To Next Page
