ATTACHMENTS ON HANDLE
NOTE
: If the floor nozzle is attached,
turn vacuum cleaner off before removing
handle from wand.
1. Press wand release button and pull up on
handle.
2. Slide attachments onto handle as
needed. To use the bare floor tool, align
the middle hole on the bare floor tool with
the tab on the handle and push together.
The bare floor tool will click into place.
See ATTACHMENT USE TABLE (page 15).
Nozzle Release
Button
ATTACHMENTS ON WAND
1. To remove floor nozzle from wand, press
the nozzle release button and pull to
remove.
2. Slide attachments onto wand as needed.
To use the bare floor tool, align the side
hole on the bare floor tool with the tab
on the wand and push together. The
bare floor tool will click into place. See
ATTACHMENT USE TABLE (page 15).
- 14 -
ATTACHMENTS
