9
ENGLISH
Installing Your Refrigerator
How to Remove and Install the Pullout Drawer
WARNING
To avoid electrical shock which can cause severe personal injury or death, disconnect power to refrigerator before
removing doors. After replacing doors, connect power.
CAUTION
To avoid possible injury, product, or property damage, you will need two people to perform the following instructions.
1
Pull drawer open to full
extension. Remove
Phillips screw from each
side of rail system.
Retain screws for later
replacement
2
Remove lower basket by
lifting basket from rail
system.
4
Lift top of door to
unhook door supports
from rail system. Lift
door out to remove.
1
Pull both rails out to full
extension.
Hook door supports into rail
tabs, as illustrated, and
lower door into final
position.
Install Phillips screws
retained from removal
step 1.
2
3
Pull upper basket out to
full extension, and lift
out to remove.
3
With drawer pulled out to
full extension, insert lower
basket by aligning tabs
on both side of lower
basket with notches in
rail assembly.
4
Slide upper basket into
unit. Make sure that
rear of basket hooks
behind rail catch.
Removing Pullout Drawer Installing Pullout Drawer
To Next Page
