ASSEMBLY INSTRUCTIONS
Before assembling the vacuum cleaner,
check the PACKING LIST (page 2). Use this
list to verify that you have received all the
components of your new Kenmore
vacuum cleaner.
Please pay special attention to these hazard alert boxes, and follow any instruc-
tions given. WARNING statements alert you to such hazards as fire, electric
shock, burns and personal injury.
CAUTION
statements alert you to such hazards
as personal injury and/or property damage.
WARNING
Electrical Shock Hazard
DO NOT plug into the electrical supply
until the assembly is complete. Failure
to do so could result in electrical shock
or injury.
CAUTION
Do not overtighten.
Overtightening could strip the screw
holes.
Do not operate the vacuum cleaner
without the screw in place.
1. Remove the
hose from the
hose holder.
2. Remove handle
screw from
vacuum cleaner.
3. Position
the handle
assembly as
shown in the
illustration.
Hose
Hose
Holder
Handle
Screw
4. Insert handle screw.
Using a Phillips
screwdriver, tighten
handle screw.
5. Route hose in the
hose holders as
shown.
6. Place the hose
onto the hose
holder and press
firmly into place.
-
6 -
HANDLE
To Next Page
