11
NOTE
DO NOT remove the ground screw from hinge.
Door Removal Instructions
To remove the refrigerator doors:
1. Trace lightly around the door’s top hinges with a
pencil. This makes reinstallation easier.
2. Disconnect the harness by grasping both sides of the
connector rmly, depress the latch, and pull apart.
Remove the two (2) screws from the top hinge. Lift
the door o of the bottom hinge and set it aside.
Getting Through Narrow Spaces
If your refrigerator will not t through an entrance area,
you can remove the doors. Check rst by measuring the
entrance.
To prepare for removing the doors:
1. Make sure the electrical power cord is unplugged
from the wall outlet.
2. Open the freezer drawer and remove the toe grille
(see “Installation” section).
3. Remove any food from the door shelves and close
the doors.
To remove the top hinge covers:
1. Remove the two (2) screws from each cover over the
top door hinges.
2. Lift inside edge of hinge cover and tilt back.
To Next Page
