9
NOTE
View shown is looking up at the bottom of the
refrigerator door.
To adjust the door stop:
Door stop is adjustable between 85 to 145 degrees.
1. Open door to provide access to screw.
2. Loosen screw.
3. Adjust door to desired location.
4. Rotate door stop until it makes contact with the
lower hinge.
5. Re-tighten screw.
Loosen or Remove
Screw
Open
Door
90
degrees
Bottom of Door
A
B
Loosen/Remove Screw (where applicable)
6. Ensure door stops in desired location before resuming
normal use.
To level the doors using the adjustable lower hinge
(select models):
1. Remove all food items from door bins on door being
adjusted.
2. Open doors to 90 degrees.
3. Loosen or remove screw.
Adjusting Door
Re-tighten Screw
Adjustable Door Stop
Installation (Continued)
NOTE
Adjustable hinge should only be used after doors have
been leveled with rollers.
To Next Page
