NOTE:
Check to make sure the small
wheel bracket is properly fixed by the
lower plate and cannot be lifted off.
10. Reinstall six screws into the lower plate.
Do not over-tighten the screws.
9. Reinstall the lower plate by aligning tabs
on front edge of lower plate with slots in
the nozzle first, and then press the lower
plate to installed position.
BELT CHANGING
Small Wheel
Bracket
√
End
Cap
II
End
Cap
I
