DIAGNOSTIC: Displaying Line Voltage
Used to display the line voltage currently be-
ing measured by the machine control:
After all saved fault codes have been dis-
played, press the Cycle Signal button. The
last 2 digits of the voltage value will be dis
-
played on the dual 7-segment display.
A Dryness Level modifier LED will also be il
-
luminated to indicate the voltage range cor
-
responding to the number displayed. The
Dryness Level LEDs relate to specific voltage
ranges as follows:
The More LED will be illuminated for high
voltage readings (above 132 VAC).
The Normal LED will be illuminated for nor
-
mal voltage readings (90-132 VAC).
The Less LED will be illuminated for low
voltage readings (below 90 VAC).
•
•
•
Now press any key (except Stop) and the
control will advance through each step of the
following sequence:
Press/
hold 2-5
seconds
Release
for 2-5
seconds
Press/
hold 2-
5
second
s
Release
for 2
-5
seconds
Press/
hold 2-5
seconds
Release
for 2-5
seconds
Press/
hold 2-5
seconds
1. Turn on motor.
Flash “Heavy Duty” LED.
2. Motor + Heater. Flash “Casual” LED.
3. No loads on. Flash “Normal” LED.
4. Start sequence again at 1.
DEACTIVATING THE
MANUAL LOAD TEST
Press the Stop button to exit this mode.
DEACTIVATING THE DIAGNOSTIC
TEST MODE
Press the Stop button twice to exit diagnos-
tics.
ACTIVATING THE MANUAL LOAD TEST
1. Be sure the dryer is in standby mode
(plugged in with all indicators off, or with
only the Clothes Dry indicator on).
2. Select any one button (except Stop) and
follow the steps below, using the same
button (remember the button):
