CONNECTION/INSTALLATIONCONNECTION/INSTALLATION
❏ Connecting microphone for Bluetooth
Connect the microphone (8) to the MIC terminal.
• To install the microphone, peel off the adhesive
tape, fix on the installation position, then adjust
the direction of the microphone to face the driver.
After installing, fix the microphone cable to the car
with clamps (commercially available).
8
Removing the unit (Only for DDX794/
DDX774BH/DDX594/DDX574BH/DDX394)
❏ Removing the trim plate
1 Engage the catch pins on the extraction
key (4) and remove the two locks on the
lower part. Lower the frame and pull it
forward.
4
2 Remove from the upper two catches.
• The frame can be removed from the top side in
the same manner.
❏ Removing the unit
1 Remove the trim plate. (See the left
column.)
2 Insert the two extraction keys (4), then
pull them as illustrated so that the unit can
be removed.
4
• Be careful to avoid injury from the catch pins on
the extraction key.
2017DDX-EntryK.indb842017DDX-EntryK.indb84 2016/10/3113:122016/10/3113:12

Kenwood DDX394 Specifications

General

Screen Size	6.2 inches
Display Resolution	800 x 480 pixels
Bluetooth	Yes
USB Ports	1
Built-in Navigation	No
Apple CarPlay	No
Android Auto	No
DVD Player	Yes
Backup Camera Input	Yes
Peak Output	50 watts
AUX Input	Yes
AM/FM Tuner	Yes
CD Playback	Yes
Steering Wheel Control Compatible	Yes
Audio Formats Supported	MP3, WMA, AAC, FLAC
Video Formats Supported	MPEG-1, MPEG-2, WMV
Preamp Outputs	3
Power Output	22 watts RMS
SiriusXM	Yes (optional tuner required)
