Setting Up
71English
To register original image
You can load an image from the connected
USB device and set it for the background
image.
Before operating this procedure, it is necessary
to connect the device which has the image to
load.
1
Touch [User1 Select] or [User2 Select] in
the Background screen.
2
Select the image to load.
3
Touch [Enter].
 The selected image is loaded and the
display returns to the Background
screen.
NOTE
• Touching [ ] rotates counter clockwise.
• Touching [
] rotates clockwise.
• Picture files: JPEG (.jpg, .jpeg), PNG (.png), BMP
(.bmp)
AV Setup
You can set AV parameters.
1
Press the [MENU] button.
 Popup menu appears.
2
Touch [SETUP].
 SETUP screen appears.
3
Touch [AV].
 AV screen appears.
4
Set each item as follows.
■ AV-OUT
You can select an AV source to be output
from the AV OUTPUT port.
OFF, AV-IN, DISC, USB, or iPod
You cannot select iPod if it is connected via
Bluetooth.
If you select USB, iPod, Disc, Spotify, Pandora,
Bluetooth audio, Apple CarPlay or Android
Auto as the main source, you cannot select
USB or iPod as the AV output source.
■ CarPlay Sidebar
Select the position of the control bar (left or
right) shown on the touch panel.
“Left” (Default)/ “Right”
■ OEM SETUP
Confirm the information about/ change the
settings for using the ADS adapter.
