Kenwood KSC-256 Service Manual

KSC-256/316/326/356
8
Ref. No. Address
New
parts
Parts No. Description Destination
KSC-256/326/316/356
11A
✽
A02-4058-08 CABINET
22A
✽
A02-4059-08 CHARGING SLOT (KSC-256)
22A
✽
A02-4060-08 CHARGING SLOT (KSC-326)
22A
✽
A02-4061-08 CHARGING SLOT (KSC-316) E,T
22A
✽
A02-4062-08 CHARGING SLOT (KSC-356) X,E,T
4 1A,2A
✽
B11-1867-08 ILLUMINATION GUIDE
52A
✽
B30-2320-08 LED
61A
✽
B43-1628-08 BADGE (KENWOOD)
-
✽
B62-2118-00 INSTRUCTION MANUAL K, X
-
✽
B62-2119-00 INSTRUCTION MANUAL E, T
93A
✽
E03-0462-08 AC INLET
10 2A,2B
✽
E29-1223-08 TERMINAL (CHARGING)
-
✽
E30-7668-08 AC CORD K
-
✽
E30-7669-08 AC CORD X
-
✽
E30-7670-08 AC CORD E
-
✽
E30-7671-08 AC CORD T
13 2A
✽
F15-1018-08 SHADING TUBE
14 2A
✽
F53-0428-08 FUSE
16 3A,3B
✽
J02-1303-08 FOOT
A2A
✽
N09-6588-08 SCREW (AC INLET)
B 3A,3B
✽
N09-6589-08 SCREW (PCB,BOTTOM)
C 3A,3B
✽
N09-6590-08 SCREW (PCB,SLOT,CABINET)
D 3A,3B
✽
N09-6591-08 SCREW (FOOT)
F 2A,3A
✽
N19-2205-08 WASHER (PCB-SLOT)
G 3A,3B
✽
N19-2206-08 WASHER (FOOT)
H 3A,3B
✽
N19-2207-08 SPRING WASHER (FOOT)
18 3A
✽
S66-0407-08 POWER SWITCH
PARTS LIST
