PARTS LIST
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
Ref. No
Add-
ress
New
Parts
Description
Desti-
nation
Re-
marks
Parts No.
D613 ✽ B30-2540-08 LED E4T1T2
D613 ✽ B30-2540-08 LED M1M2M3
D613 ✽ B30-2540-08 LED Q1Q2Y1
D613 ✽ B30-2540-08 LED X1X2X3
IC601 ✽ LC867224A-5H71 IC
Q601,602 2SC945 TRANSISTOR
Q603 2SA733 TRANSISTOR E1E2E3
Q603 2SA733 TRANSISTOR E4T1T2
Q603 2SA733 TRANSISTOR M1M2M3
Q603 2SA733 TRANSISTOR Q1Q2Y1
Q603 2SA733 TRANSISTOR X1X2X3
Q604 2SA733 TRANSISTOR
RM601 ✽ W02-2680-08 REMOTE RECEIVER
- ✽ B06-0057-08 GRILLE ASSY(BLACK L) E3E4 B
- ✽ B06-0057-08 GRILLE ASSY(BLACK L) T2Q2X3 B
- ✽ B06-0058-08 GRILLE ASSY(BLACK R) E3E4 B
- ✽ B06-0058-08 GRILLE ASSY(BLACK R) T2Q2X3 B
- ✽ B06-0059-08 GRILLE ASSY(GRAY L) E1E2T1 H
- ✽ B06-0059-08 GRILLE ASSY(GRAY L) K1P1Y1 H
- ✽ B06-0059-08 GRILLE ASSY(GRAY L) M1M2X1 H
- ✽ B06-0059-08 GRILLE ASSY(GRAY L) Q1 H
- ✽ B06-0060-08 GRILLE ASSY(GRAY R) E1E2T1 H
- ✽ B06-0060-08 GRILLE ASSY(GRAY R) K1P1Y1 H
- ✽ B06-0060-08 GRILLE ASSY(GRAY R) M1M2X1 H
- ✽ B06-0060-08 GRILLE ASSY(GRAY R) Q1 H
- ✽ H50-2991-08 ITEM CARTON CASE(LS-N301) E3E4T2
- ✽ H50-2991-08 ITEM CARTON CASE(LS-N301) Q2
- ✽ H50-2997-08 ITEM CARTON CASE(LS-N351) E2M3
- ✽ H50-2997-08 ITEM CARTON CASE(LS-N351) T1E1Q1
- ✽ H50-2998-08 ITEM CARTON CASE(LS-N371S) M1M2
- ✽ T03-0505-08 TWEETER UNIT(MULTIPLE)
- ✽ T10-1004-08 WOOFER UNIT(40W 5INCH)
- ✽ T10-1005-08 WOOFER UNIT(60W 6.5INCH)
- ✽ W03-5839-05L SPEAKER(LS-N301)LEFT E3E4
- ✽ W03-5839-05R SPEAKER(LS-N301)RIGHT E3E4
- ✽ W03-5839-05L SPEAKER(LS-N301)LEFT T2Q2X3
- ✽ W03-5839-05R SPEAKER(LS-N301)RIGHT T2Q2X3
- ✽ W03-5840-05L SPEAKER(LS-N351)LEFT K1P1Q1
- ✽ W03-5840-05R SPEAKER(LS-N351)RIGHT K1P1Q1
- ✽ W03-5840-05L SPEAKER(LS-N351)LEFT T1E1E2
- ✽ W03-5840-05R SPEAKER(LS-N351)RIGHT T1E1E2
- ✽ W03-5840-05L SPEAKER(LS-N351)LEFT X2M3
- ✽ W03-5840-05R SPEAKER(LS-N351)RIGHT X2M3
- ✽ W03-5841-05L SPEAKER(LS-N371)LEFT M1X1Y1
- ✽ W03-5841-05R SPEAKER(LS-N371)RIGHT M1X1Y1
- ✽ W03-5841-05L SPEAKER(LS-N371)LEFT M2
- ✽ W03-5841-05R SPEAKER(LS-N371)RIGHT M2
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East, Hawaii) T : Europe E : Europe G : Germany V : China (Shanghai) B : BLACK S : SILVER H : GRAY
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components.
&
SPEAKER
HOW TO READ THE PARTS LIST
ABBREVIATION OF MODEL AND MASS PRODUCTION'S DESTINATIONS
MODEL ABB. Australia Canada China England Europe Germany Korea Malaysia
RXD-251 - X2 - - - - - - -
RXD-301 - X3 - - T2 E3 - - -
RXD-301E - - - - - E4 - - -
RXD-301W - - - - - - - - -
RXD-351 - X1 - - T1 E1 - - -
RXD-351E - - - - - E2 - - -
RXD-351W - - - - - - - - -
RXD-371S - - - - - - - - -
RXD-A3 - - P1 - - - - - -
MODEL ABB. Mexico PX/AAFES Russia Scandinavia Shanghai USA Other area
RXD-251 - - - - - - - M3 -
RXD-301 - - - - - - - - -
RXD-301E - - - - - - - - -
RXD-301W - - - Q2 - - - - -
RXD-351 - - Y1 - - - - M1 -
RXD-351E - - - - - - - - -
RXD-351W - - - Q1 - - - - -
RXD-371S - - - - - - - M2 -
RXD-A3 - - - - - - K1 - -
Note :
Every individual parts is not available for repair parts on
cassette and cd mechanisms.
Schematic is printed to check cd-circuitry, however, no
parts list in this manual.
