Keter MANOR 6x8SD - Front Wall and Door Frame Assembly; Front Panels and Door Frame Installation

fd2b (x2)
6.7" x 51.5"
17 x 131 cm
21
s26b (x6)
1”
26 mm
fd2b
fd2b
s26b
fd2b
This side
up
FRONT WALL & DOOR FRAME ASSEMBLY | ASSEMBLAGE DU MUR DE DEVANT ET DU CADRE DE LA PORTE | MONTAJE DEL MARCO DE LA
PUERTA Y DE LA PARED FRONTAL | MONTAGE DER VORDEREN WAND & DES TÜRRAHMENS | MONTEREN VOORSTE MUUR EN DEURFRAME
| ASSEMBLAGGIO DEL MURO FRONTALE E DEL TELAIO DELLA PORTA | MONTAGEM DA PAREDE FRONTAL E DA ESTRUTURA DA PORTA
22
rm (x1)lm (x1)
Left
Gauche
Izquierdo
Verließ
Links
Sinistra
esquerdo
Right
Droit
Derecho
Richtig
Rechts
Destra
Direito
rm
lm
rm
lm
fu2a (x1)
23
s26b (x4)
1”
26 mm
fu2a
s26b
mdfl
24
mdfl (x1)
70.4”
179 cm
Self drill screw
ds2b (x1)
0.39”
10 mm
1
mdfl
2
2
18
19
