62 KETRON • AUDYA
Style Mode
DRUM (1)
▀
By pressing the USER 2 (DRUM) once you can •
access to the first edit window of the audio drum
(Figure 151):
F1–LIVE DRUM: sets the STRETCH or PITCH
mode for Audio Style Modeling of the live drum.
The STRETCH algorithm (default) guarantees a
good audio quality even changing the tempo.
The available range is -30% up to +38% of the
nominal speed of the wave.
The PITCH algorithm matches the tempo change
of the sample altering the audio content. The
available range is -30% up to +38%.
F3–BASS FREQ EQ: adjusts the EQ low frequency
of the audio drum from 50 Hz to 990 Hz.
F4–TREBLE FREQ EQ: adjusts the EQ high
frequency of the drum from 1030 Hz to 16130 Hz.
F8–BASS GAIN EQ: adjusts the EQ low frequency
gain by +/-12 dB.
F9–TREBLE GAIN EQ: adjusts the EQ high
frequency gain by +/-12 dB.
Storing the DRUM parameters
The parameters of LIVE DRUM (Stretch and Pitch) •
and the 2-bands parametric EQ for the audio
drum can be saved as USER STYLE with any
frequency (FREQ) and gain (GAIN) values.
Press the SAVE button on the front panel and give
a name by using the keyboard or use the same
style name, as shown in Figure 152, by pressing
the USER 5 button (SAVE).
DRUM (2)
▀
By pressing the USER 2 button twice (DRUM •
turns off, as shown by the arrow on Figure 153)
you can access the AUTOCRASH parameters
(Figure 153), that is the automatic hit on the
cymbals (CRASH).
F1–AUTOCRASH INTRO: the Autocrash function
can be enabled/disabled after the Intro of the
style.
F2–AUTOCRASH FILL/B: the Autocrash function
can be enabled/disabled after the Fill In and the
Break of the style.
Figure 151
Figure 152
Style Mode
Figure 153
NOTE
The AUTOCRASH works only if present within the style.
If the Autocrash is not programmed into the style its
two options have no effect.
