Owner’s Manual DG100
109
This is the only menu that is to be called up from the initial page of the MIDI menu and is used to access some
settings dedicated to the MIDI ports. The parameters, the value of which is called up by pressing the relative
function push button repeatedly, are:
F1 MIDI In 1: This is used to modify the initial setting of the MIDI port from GM to Keyboard.
F2 MIDI In2/Computer: The same as F1 MIDI In 1. The setting also establishes the type of MIDI input
used by the Interface Computer.
F3 MIDI Out: This establishes which group of MIDI channels will be sent to MIDI Out.
F4 Computer Out: This establishes which group of MIDI channels will be sent to the Computer Interface.
F5 Escape: This returns to the initial page of the MIDI menu.
F6 Computer: This selects the type of computer to which the DG100 is connected.
F7 Local On/Off: This is a MIDI condition for which, when set as Off, all the DG100 sections are no longer
controlled by the keyboard but only by the MIDI In input.
CALLING UP THE PROGRAMS, THE ONE TOUCH MEMORIES AND THE REGISTRATIONS VIA MIDI
Program: Send the relative Program Change to the MIDI channel associated to the Right section.To assure a good reception, before you send the
Program Change, ensure that the PROGRAM push button is enabled (LED lit).
One Touch: send the relative Program Change on the MIDI channel associated to the Right section. To asure a good reception, before you send
the Program Change, ensure that the 1TOUCH push button is enabled (LED lit).
Registration: Send the relative Program Change on the MIDI channel associated to the Registrations. The status of the REGISTRATION push but-
ton is not important.
BANK SELECT AND PROGRAM CHANGE
We are providing a complete list of the Bank Select (CC 0) and Program Change values relative to the Pre-set Voices, User Voices, Drum Sets and
Flash RAM. The DG100 only uses the Control Change 00 as Bank Select.
