SD5
198
CCHHOORRUUSS PPAARRAAMMEETTEERRSS
F0H 26H 7BH Cho_par 00H Value F7H
Cho_par: 3BH Chorus Volume Value 0 - 7FH
74H "" Delay " 0 - 7FH
75H "" Feedback " 0 - 7FH
76H "" Rate " 0 - 7FH
77H "" Depth " 0 - 7FH
DDEELLAAYY PPAARRAAMMEETTEERRSS
F0H 26H 7BH Delay_par 00h Value F7H
Delay_par: 2BH Delay Feed Value 0 - 7FH
2CH " Filter " 0 - 68H
Delay Time: F0H 26H 7BH 29h 00H Time_Center(0-7FH) Time_Left(0-7FH) Time_right(0-7FH) F7H
Delay Volume: F0H 26H 7BH 2Ah 00H Vol_Center(0-7FH) Vol_Left(0-7FH) Vol_right(0-7FH) F7H
DDIISSTTOORRSSOORR PPAARRAAMMEETTEERRSS
F0H 26H 7BH Dist_par 00H Value F7H
Dist_par: 22H Distorsor Volume Value 00H - 7FH
25H "" Tone " 10H - 66H
26H "" Resonance " 18H - 7FH
MMIICCRROOPPHHOONNEE PPAARRAAMMEETTEERRSS
F0H 26H 7BH Micro_par 00H Value F7H
Micro_par: 50H Micro. ON/OFF Value 00H = OFF; 7FH = ON Micro_par: 55H Micro. Right Echo Value 00H - 7FH
51H Micro. Right Volume Value 00H - 7FH 56H Micro. Left Echo Value 00H - 7FH
52H Micro. Left Volume Value 00H - 7FH 57H Micro. Right Reverb Value 00H - 7FH
53H Micro. Right Pan Value 00H - 7FH 58H Micro. Left Reverb Value 00H - 7FH
54H Micro. Left Pan Value 00H - 7FH
SSPPLLIITT PPOOIINNTT
F0H 26H 7BH 03H 00H Key F7H Key = 00H - 7FH
GGLLOOBBAALL TTRRAANNSSPPOOSSEERR
F0H 26H 7BH 07H 00H Value F7H Value = 28H - 58H; 40H = no transp.
SSTTYYLLEE NNUUMMBBEERR
F0H 26H 7BH 08H 00H Numc Numd F7H Numc=0-9 Numd = 0-99
Examples:
Numc=2 Numd=13 select style number 213 Numc=1 Numd=0 select style number 100
SSOONNGG NNUUMMBBEERR
F0H 26H 7BH 09H 00H Numc Numd F7H Numc=0-9 Numd = 0-99
Examples:
Numc=1 Numd=23 select song number 123 Numc=2 Numd=3 select song number 203
SSCCAALLEE TTUUNNIINNGG ((AARRAABBIICC))
F0H 26H 7BH 0AH Chan Data1...Data12 F7H Data: 00H-7FH; 40h = no detune
Chan: 00H-0FH Chan: 7EH lower channels
0H right channels 7FH all channels
Technical Tables
