Installation Instructions
Supreme Air LV Bench Hood
Fume Hood w/Auto-return Sash
K
ewaunee Scientific Corporation • P.O. Box 1842 • Statesville, North Carolina 28687-1842 • Phone 704-873-7202
IILV05-SA 06/05-2
Figure 1
Figure 2
FUME HOOD
LIGHT FIXTURE
FUME HOOD
WORKSURFACE
LOWER AIRFOIL
FRONT PANEL
END PANEL
REAR BAFFLES
#8 x 1/2" Pan Head
Sheet Metal Screw
10-24 x 3/4" Phillips Truss
Head Machine Screw
w/Nut & Washer
#8 x 1/2" Pan Head
Sheet Metal Screw
(2 Required)
10-24 x 3/4" Phillips Truss
Head Machine Screw
w/Nut & Washer
4ft. Hood – 4 Required
5ft. Hood – 5 Required
6ft. Hood – 5 Required
7ft. Hood – 6 Required
8ft. Hood – 7 Required
Detail 1
AUTO-RETURN
PULLY
SASH
WEIGHT
BOX
WEIGHT
GUIDE
AUTO-RETURN
WEIGHT
REAR SASH
PULL
Y
ACCESS PANEL
